Myinfo (Singpass) v5 integration in Next.js 16

Sebastian

Oct 30, 2025 • 12 min read

A production-ready Next.js application implementing MyInfo (Singpass) v5 integration with full OAuth2.1/OIDC FAPI 2.0 compliance.

Repository: https://github.com/sebastiansieber/myinfo-integration

Overview
Features
Prerequisites
Installation
Configuration
Deployment
- Docker Deployment
- Vercel/Railway Deployment
Testing
Architecture
API Routes
Security Features
Troubleshooting
Production Checklist

Overview

This application demonstrates a complete MyInfo v5 integration following the OAuth2.1 Authorization Code Flow with PKCE, DPoP (Demonstration of Proof-of-Possession), and JWT-based client authentication. It retrieves user data from Singapore's MyInfo service after Singpass authentication.

Key Standards Implemented:

OAuth 2.1 (RFC 6749 + enhancements)
OpenID Connect (OIDC)
FAPI 2.0 (Financial-grade API)
PKCE (RFC 7636)
DPoP (RFC 9449)
JWT Client Authentication (RFC 7523)

Features

✅ Complete OAuth2.1/OIDC Flow

Authorization with PKCE (Proof Key for Code Exchange)
JWT-based client assertion (no static secrets)
DPoP token binding for enhanced security
Adaptive Bearer/DPoP authorization (staging compatibility)

✅ Secure Data Handling

JWE (JSON Web Encryption) for data encryption
JWS (JSON Web Signature) for data integrity
Ephemeral key generation per session
Secure session management

✅ Production Ready

TypeScript for type safety
Docker support with Docker Compose
Environment-based configuration
Comprehensive error handling
JWKS endpoint for public key distribution

Prerequisites

Before you begin, ensure you have:

Node.js 18.x or higher
npm or yarn package manager
Docker and Docker Compose (for Docker deployment)
Singpass Developer Portal Account (Register here)
OpenSSL (for key generation)
A publicly accessible domain with HTTPS (required for Singpass)

Installation

1. Clone the Repository

git clone <repository-url>
cd myinfo-test

2. Install Dependencies

npm install

This installs:

next - Next.js framework
react & react-dom - React library
axios - HTTP client
jose - JOSE (JWT/JWE/JWS) library
TypeScript and related types

Configuration

Singpass Developer Portal Setup

Step 1: Create a New App

Log in to the Singpass Developer Portal
Navigate to My Apps → Create New App
Fill in the app details:
- App Name: test-app (or your preferred name)
- Industry: Select your industry
- App Category: General
- Description: Brief description of your app

Step 2: Configure App Settings

Navigate to your app's configuration page and set:

General Settings:

Profile Type: UUID only (or UUID + NRIC based on your needs)
Authentication Type: 1FA (or 2FA for production)
Site URL(s): https://yourdomain.com
Redirect URL(s): https://yourdomain.com/redirect
- ⚠️ Must be HTTPS (except localhost for development)
- Must match exactly what you use in the authorization request
JWKS Endpoint: https://yourdomain.com/.well-known/jwks.json
- This is where you'll serve your public keys
- Must be publicly accessible (no authentication required)
- Must be on port 443 (HTTPS)

Scopes Selection:

Select the data attributes you need (e.g., name, email, mobileno)
For this test app: openid, name

App Purpose:

Purpose Description: "Test MyInfo integration" (or your actual purpose)
This is shown to users during consent

Security:

Assurance Level: 2 (standard for most apps)

Step 3: Note Your Credentials

After creating the app, you'll receive:

App ID (Client ID): e.g., KD5ZM*************************heqQV
This is your MYINFO_CLIENT_ID

Key Generation

MyInfo v5 requires two ECDSA P-256 key pairs:

Signing Key: For client assertion JWTs
Encryption Key: For decrypting MyInfo data

Generate Keys with OpenSSL

# Generate signing key pair (PKCS8 format for private key)
openssl ecparam -name prime256v1 -genkey -noout -out signing-private.pem
openssl pkcs8 -topk8 -nocrypt -in signing-private.pem -out signing-private-pkcs8.pem
openssl ec -in signing-private-pkcs8.pem -pubout -out signing-public.pem

# Generate encryption key pair (PKCS8 format)
openssl ecparam -name prime256v1 -genkey -noout -out encryption-private.pem
openssl pkcs8 -topk8 -nocrypt -in encryption-private.pem -out encryption-private-pkcs8.pem
openssl ec -in encryption-private-pkcs8.pem -pubout -out encryption-public.pem

Alternative: Use SEC1 Format (also supported)

# If you already have SEC1 format keys, they work too
openssl ecparam -name prime256v1 -genkey -noout -out signing-private-sec1.pem
openssl ec -in signing-private-sec1.pem -pubout -out signing-public.pem

Important Notes:

⚠️ Keep private keys secure: Never commit them to version control
🔄 Use different keys for staging and production
📝 PKCS8 format is recommended but SEC1 format also works
🔑 The public keys will be served via your JWKS endpoint

Environment Variables

Create `.env` file

Create a .env file in the project root (for Docker) or .env.local (for local development):

# MyInfo Configuration
MYINFO_ENV=staging
MYINFO_CLIENT_ID=your_client_id_from_portal
MYINFO_REDIRECT_URI=https://yourdomain.com/redirect
MYINFO_JWKS_URI=https://yourdomain.com/.well-known/jwks.json
MYINFO_SCOPES=openid name

# Private Keys (PKCS8 or SEC1 format)
MYINFO_SIGNING_PRIVATE_KEY="-----BEGIN EC PRIVATE KEY-----\n******\n-----END EC PRIVATE KEY-----"

MYINFO_ENCRYPTION_PRIVATE_KEY="-----BEGIN EC PRIVATE KEY-----\n******\n-----END EC PRIVATE KEY-----"

# Next.js Configuration
NEXT_PUBLIC_SITE_URL=https://yourdomain.com

For Production Deployment

If using PKCS8 format (recommended):

MYINFO_SIGNING_PRIVATE_KEY="-----BEGIN PRIVATE KEY-----\n******\n-----END PRIVATE KEY-----"

Important Environment Variable Notes:

Multi-line Keys:
- Wrap the entire key (including headers) in quotes
- Use actual newlines or \n characters
- Docker/Next.js will handle both formats
MYINFO_REDIRECT_URI:
- Must match exactly what's in the Singpass portal
- Must be HTTPS (except localhost)
- No trailing slash
MYINFO_JWKS_URI:
- Must be publicly accessible
- Must return your public keys in JWKS format
- Will be accessed by Singpass servers
NEXT_PUBLIC_SITE_URL:
- Used for OAuth redirects
- Must be your public domain
- Required for Docker deployments behind reverse proxy

Deployment

Docker Deployment

This is the recommended deployment method for production.

1. Build the Docker Image

docker-compose build

2. Start the Application

docker-compose up -d

The app will be available on port 3000 (configure your reverse proxy to forward to it).

3. Configure Reverse Proxy (e.g., Traefik, Nginx)

Example Traefik labels in docker-compose.yml:

labels:
  - "traefik.enable=true"
  - "traefik.http.routers.myinfo.rule=Host(`your-domain.com`)"
  - "traefik.http.routers.myinfo.entrypoints=websecure"
  - "traefik.http.routers.myinfo.tls.certresolver=letsencrypt"
  - "traefik.http.services.myinfo.loadbalancer.server.port=3000"

Example Nginx configuration:

server {
    listen 443 ssl http2;
    server_name your-domain.com;

    ssl_certificate /path/to/cert.pem;
    ssl_certificate_key /path/to/key.pem;

    location / {
        proxy_pass http://localhost:3000;
        proxy_set_header Host $host;
        proxy_set_header X-Real-IP $remote_addr;
        proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
        proxy_set_header X-Forwarded-Proto $scheme;
    }
}

4. Verify JWKS Endpoint

After deployment, verify your JWKS endpoint is accessible:

curl https://yourdomain.com/.well-known/jwks.json

Expected response:

{
  "keys": [
    {
      "kty": "EC",
      "x": "...",
      "y": "...",
      "crv": "P-256",
      "kid": "sig-key-1",
      "use": "sig",
      "alg": "ES256"
    },
    {
      "kty": "EC",
      "x": "...",
      "y": "...",
      "crv": "P-256",
      "kid": "enc-key-1",
      "use": "enc",
      "alg": "ECDH-ES+A256KW"
    }
  ]
}

⚠️ Verify that the d parameter (private key) is NOT present in the JWKS!

Vercel/Railway Deployment

1. Set Environment Variables

In your deployment platform's dashboard, add all the environment variables from your .env file.

Important for multi-line keys:

# Use literal \n for newlines in the platform UI
MYINFO_SIGNING_PRIVATE_KEY="-----BEGIN EC PRIVATE KEY-----\nMHcCAQEE...\n-----END EC PRIVATE KEY-----"

2. Deploy

# Vercel
vercel --prod

# Railway
railway up

3. Configure Custom Domain

Set up your custom domain in the platform's DNS settings and ensure HTTPS is enabled.

Testing

Testing in Staging Environment

1. Navigate to Your App

https://yourdomain.com

This initiates the OAuth flow and redirects you to Singpass staging.

3. Use Test Credentials

In the Singpass Developer Portal, you'll find test personas with demo credentials:

Test NRIC numbers
Demo Singpass passwords
Various data scenarios

Example Test Users:

NRIC: S9812381D (use the test credentials provided in the portal)

After login, you'll see a consent screen showing:

The data being requested (e.g., name)
Your app's purpose
Option to approve or deny

5. View Retrieved Data

After granting consent, you'll be redirected back to your app with the name displayed:

Success!
Name retrieved from MyInfo: John Doe

Troubleshooting Test Issues

If you get "Request parameters invalid" (PX-E1000):

Verify your redirect URI matches exactly
Check that JWKS endpoint is accessible
Ensure environment variables are loaded

If you get "Invalid JWKS object" (PX-E0101):

Verify JWKS endpoint returns valid JSON
Check that private keys (d parameter) are NOT in the JWKS
Ensure both signing and encryption keys are present

If you get 401 on userinfo:

This is expected in staging if token_type is "Bearer"
The app automatically adapts to Bearer tokens in staging

If name shows "Unknown":

Check server logs for decryption errors
Verify encryption private key is correct
Ensure MyInfo JWKS is accessible for signature verification

Architecture

OAuth 2.1 Flow Overview

┌─────────┐                                         ┌──────────────┐
│         │  1. Initiate Login                     │              │
│  User   │───────────────────────────────────────>│   Your App   │
│ Browser │                                         │              │
└─────────┘                                         └──────────────┘
     │                                                      │
     │  2. Redirect to Singpass                           │
     │  (with PKCE code_challenge)                        │
     │<───────────────────────────────────────────────────┘
     │
     │                                              ┌──────────────┐
     │  3. Login & Consent                         │              │
     │─────────────────────────────────────────────>│  Singpass    │
     │                                              │  (MyInfo)    │
     │  4. Redirect back with auth code            │              │
     │<─────────────────────────────────────────────│              │
     │                                              └──────────────┘
     │
     │                                              ┌──────────────┐
     │  5. Exchange code for token                 │              │
     │  (with code_verifier + client_assertion     │   Your App   │
     │   + DPoP proof)                             │   Backend    │
     │─────────────────────────────────────────────>│              │
     │                                              └──────┬───────┘
     │                                                     │
     │                                                     │ 6. Request person data
     │                                                     │    (with access_token
     │                                              ┌──────▼───────┐  + DPoP proof)
     │                                              │              │
     │                                              │  Singpass    │◄────┐
     │                                              │  (MyInfo)    │     │
     │                                              │              │─────┘
     │                                              └──────┬───────┘
     │                                                     │
     │  7. Display data                            ┌──────▼───────┐
     │<─────────────────────────────────────────────│   Your App   │
     │                                              │              │
     │                                              └──────────────┘

Detailed Flow Steps

Step 1: Authorization Request

Route: /api/auth/myinfo

Generate ephemeral ECDSA P-256 key pair (for DPoP)
Generate PKCE code_verifier and code_challenge
Store session data (code_verifier, state, ephemeral keys)
Redirect to Singpass /auth endpoint with:
- client_id: Your App ID
- scope: openid name (or other requested scopes)
- redirect_uri: Your callback URL
- response_type: code
- code_challenge: SHA-256 hash of code_verifier
- code_challenge_method: S256
- state: Random string for CSRF protection
- nonce: Random string for ID token validation

User authenticates with Singpass and grants consent to share data.

Step 3: Authorization Callback

Route: /redirect

Singpass redirects back with:

code: Authorization code
state: Your state value (verify it matches)

Step 4: Token Exchange

Internal: exchangeToken() function

Generate Client Assertion JWT:
- Signed with your signing private key
- Contains cnf.jkt claim with ephemeral key thumbprint
- Claims: iss, sub, aud, iat, exp, jti, cnf
Generate DPoP Proof JWT (for token request):
- Signed with ephemeral private key
- Contains ephemeral public key in header
- Claims: jti, htm, htu, iat, exp
POST to /token endpoint with:
- Form data: grant_type, code, redirect_uri, client_id, code_verifier, client_assertion_type, client_assertion
- Header: DPoP: <dpop_proof_jwt>
Receive:
- access_token: Bearer token (in staging) or DPoP-bound token (in production)
- id_token: Encrypted JWT with user info
- token_type: "Bearer" or "DPoP"

Step 5: Person Data Retrieval

Internal: getPersonData() function

Check token_type:
- If "DPoP": Generate new DPoP proof with ath claim (access token hash)
- If "Bearer": Use standard Bearer authorization
GET /userinfo endpoint with:
- Header: Authorization: Bearer <token> or Authorization: DPoP <token>
- Header (if DPoP): DPoP: <dpop_proof_jwt>
Receive encrypted response (JWE format)

Step 6: Data Decryption & Verification

Internal: decryptAndVerifyPersonData() function

Decrypt JWE:
- Use your encryption private key
- Extracts the JWS (signed payload)
Verify JWS signature:
- Fetch MyInfo's public keys from their JWKS endpoint
- Verify signature with matching key
- Extract person data payload
Parse Person Data:
- Extract user attributes (name, etc.)
- Structure: { person_info: { name: { value: "..." } } }

Step 7: Display Data

Redirect user to homepage with name in query params:

https://yourdomain.com/?name=John+Doe

API Routes

`/api/auth/myinfo` (GET)

Initiates the MyInfo login flow.

Response: Redirects to Singpass authorization endpoint

Query Parameters Generated:

client_id: Your App ID
scope: Requested scopes
redirect_uri: Callback URL
response_type: code
code_challenge: PKCE challenge
code_challenge_method: S256
state: CSRF token
nonce: ID token validation token

`/redirect` (GET)

OAuth callback handler. Processes the authorization code and retrieves user data.

Query Parameters Expected:

code: Authorization code from Singpass
state: Must match the state sent in authorization request

Success Response: Redirects to /?name=<user_name>

Error Responses:

/?error=invalid_state - State mismatch (CSRF attack)
/?error=invalid_session - Session not found or expired
/?error=token_exchange_failed - Token exchange failed
/?error=callback_processing_failed - General error

`/.well-known/jwks.json` (GET)

Serves public keys in JWKS format for Singpass to encrypt data.

Response Example:

{
  "keys": [
    {
      "kty": "EC",
      "crv": "P-256",
      "x": "base64url-encoded-x-coordinate",
      "y": "base64url-encoded-y-coordinate",
      "kid": "sig-key-1",
      "use": "sig",
      "alg": "ES256"
    },
    {
      "kty": "EC",
      "crv": "P-256",
      "x": "base64url-encoded-x-coordinate",
      "y": "base64url-encoded-y-coordinate",
      "kid": "enc-key-1",
      "use": "enc",
      "alg": "ECDH-ES+A256KW"
    }
  ]
}

Important:

Must be publicly accessible (no authentication)
Must NOT contain private key components (d parameter)
Cached by Singpass for up to 1 hour
Must be HTTPS with valid certificate

Security Features

PKCE (Proof Key for Code Exchange)

Purpose: Prevents authorization code interception attacks

Implementation:

Generate random code_verifier (43-128 characters)
Compute code_challenge = BASE64URL(SHA256(code_verifier))
Send code_challenge in authorization request
Send code_verifier in token request
Singpass verifies: SHA256(code_verifier) === code_challenge

Code Location: lib/myinfo/crypto.ts - generatePKCE()

DPoP (Demonstration of Proof-of-Possession)

Purpose: Prevents token theft by binding tokens to a specific client-held key

Implementation:

Generate ephemeral ECDSA P-256 key pair per session
Include ephemeral public key thumbprint in client assertion (cnf.jkt)
Sign each request (token, userinfo) with ephemeral private key
Include ephemeral public key in DPoP JWT header
Singpass validates that the same key is used throughout the flow

Code Location:

lib/myinfo/crypto.ts - generateEphemeralKeyPair(), generateDpopProof()
lib/myinfo/service.ts - exchangeToken(), getPersonData()

JWT Client Authentication

Purpose: Eliminates static client secrets, uses asymmetric cryptography

Implementation:

Sign client assertion JWT with your signing private key
Singpass fetches your public key from JWKS endpoint
Singpass verifies JWT signature
Ensures request comes from legitimate client

Claims in Client Assertion:

iss: Your client ID (issuer)
sub: Your client ID (subject)
aud: Token endpoint URL
iat: Issued at timestamp
exp: Expiry timestamp (5 minutes)
jti: Unique JWT ID (prevents replay)
cnf.jkt: Ephemeral DPoP key thumbprint

Code Location: lib/myinfo/crypto.ts - generateClientAssertion()

JWE/JWS Encryption

Purpose: End-to-end encryption and data integrity verification

Flow:

MyInfo signs person data with their private key (JWS)
MyInfo encrypts signed data with your public key (JWE)
You receive encrypted data
You decrypt with your private key (JWE → JWS)
You verify signature with MyInfo's public key (JWS → data)

Algorithms:

JWE: ECDH-ES+A256KW (Elliptic Curve Diffie-Hellman Ephemeral Static + AES256 Key Wrap)
JWS: ES256 (ECDSA with P-256 curve and SHA-256)

Code Location: lib/myinfo/service.ts - decryptAndVerifyPersonData()

Session Management

Current Implementation: In-memory store (suitable for testing)

Structure:

{
  state: {
    codeVerifier: string,
    state: string,
    ephemeralKeyPair: {
      privateKey: CryptoKey,
      publicKey: CryptoKey,
      publicJwk: JsonWebKey,
      thumbprint: string
    }
  }
}

For Production: Replace with Redis, database, or encrypted cookies

Code Location: lib/myinfo/session.ts

Troubleshooting

Common Issues

1. "Request parameters invalid" (PX-E1000)

Symptoms: Error page from Singpass after clicking login

Causes:

Redirect URI mismatch (must match exactly in portal)
Client ID incorrect or not configured
PKCE parameters malformed

Solutions:

Verify MYINFO_REDIRECT_URI matches portal configuration
Check MYINFO_CLIENT_ID is correct
Ensure no trailing slashes in URIs

2. "Invalid JWKS object" (PX-E0101)

Symptoms: Error page from Singpass after clicking login

Causes:

JWKS endpoint not accessible
JWKS contains private key components
Invalid JSON format
Wrong key types or algorithms

Solutions:

# Test JWKS endpoint
curl https://yourdomain.com/.well-known/jwks.json

# Verify response structure
# Should have two keys: sig and enc
# Should NOT have "d" parameter (private key)

Verify JWKS format:

{
  "keys": [
    {
      "kty": "EC",
      "crv": "P-256",
      "x": "...",  // Public key X coordinate
      "y": "...",  // Public key Y coordinate
      "kid": "sig-key-1",
      "use": "sig",
      "alg": "ES256"
      // NO "d" parameter!
    },
    // ... encryption key
  ]
}

3. Token Exchange 401 Error

Symptoms: token_exchange_failed error after Singpass redirect

Causes:

Client assertion signature invalid
Private key format incorrect
DPoP proof malformed
Client assertion thumbprint mismatch

Solutions:

Verify private keys are in PKCS8 or SEC1 format
Check key file has proper header/footer
Ensure ephemeral key thumbprint is correct in client assertion
Review server logs for detailed error messages

4. Userinfo 401 Error

Symptoms: token_exchange_failed error after token is obtained

Causes:

Using DPoP authorization with Bearer token (staging issue)
Access token expired
DPoP proof signature invalid

Solutions:

Check that the app uses Bearer scheme when token_type is "Bearer"
Verify adaptive authorization logic is working
In staging, expect Bearer tokens (not DPoP-bound)

5. Name Shows "Unknown"

Symptoms: Success page shows "Unknown" instead of actual name

Causes:

Data decryption failed
JWS signature verification failed
Person data structure different than expected
Encryption private key incorrect

Solutions:

Check server logs for decryption errors
Verify MYINFO_ENCRYPTION_PRIVATE_KEY is correct
Ensure MyInfo JWKS endpoint is accessible
Check that person data structure matches expected format

Add temporary logging:

// In app/redirect/route.ts
console.log('Person data:', JSON.stringify(personData, null, 2));

6. Environment Variables Not Loading

Symptoms: undefined values in configuration

For Docker:

Verify .env file exists in project root
Check docker-compose.yml has env_file: - .env
Rebuild container: docker-compose up --build

For Local Development:

Use .env.local file (not .env)
Restart dev server: npm run dev

For Vercel/Railway:

Set environment variables in platform dashboard
Use \n for newlines in multi-line keys
Redeploy after updating variables

Debug Mode

To enable detailed logging, uncomment console.log statements in:

lib/myinfo/service.ts - Token exchange and userinfo requests
lib/myinfo/crypto.ts - Key generation and JWT creation
app/redirect/route.ts - Callback processing

Example:

// Decode access token payload
const accessTokenParts = response.data.access_token.split('.');
const accessTokenPayload = JSON.parse(
  Buffer.from(accessTokenParts[1], 'base64url').toString()
);
console.log('Access Token Payload:', accessTokenPayload);

Production Checklist

Before Going Live

1. Security Audit

[ ] Private keys secured (not in version control)
[ ] Different keys for staging and production
[ ] Environment variables properly configured
[ ] HTTPS enabled on all endpoints
[ ] JWKS endpoint publicly accessible
[ ] No private keys in JWKS response
[ ] Session storage is secure (not in-memory)

2. Singpass Portal Configuration

[ ] Production app created and configured
[ ] Correct production App ID in environment
[ ] Production redirect URI matches exactly
[ ] Production JWKS URL configured
[ ] All required scopes approved
[ ] App purpose clearly stated
[ ] Contact emails updated

3. Infrastructure

[ ] HTTPS certificate valid and not expired
[ ] Domain DNS configured correctly
[ ] Reverse proxy configured (if applicable)
[ ] Load balancer configured (if applicable)
[ ] Firewall rules allow HTTPS traffic
[ ] Health check endpoint configured

4. Testing

[ ] Full OAuth flow tested in production
[ ] Test with multiple user accounts
[ ] Error scenarios tested (deny consent, network errors)
[ ] JWKS endpoint tested from external network
[ ] Token exchange tested
[ ] Data decryption tested
[ ] Performance tested under load

5. Monitoring

[ ] Error logging configured
[ ] Application monitoring set up
[ ] Alerts configured for failures
[ ] Audit logging for data access
[ ] Rate limiting configured

6. Compliance

[ ] Privacy policy updated
[ ] Terms of service updated
[ ] Data retention policy defined
[ ] User consent recorded
[ ] PDPA compliance verified

7. Production Endpoints

Update environment variables to use production endpoints:

MYINFO_ENV=production
MYINFO_CLIENT_ID=<production_client_id>
MYINFO_REDIRECT_URI=https://yourdomain.com/redirect
MYINFO_JWKS_URI=https://yourdomain.com/.well-known/jwks.json

Production Singpass endpoints (automatically used when MYINFO_ENV=production):

Authorization: https://id.singpass.gov.sg/auth
Token: https://id.singpass.gov.sg/token
Userinfo: https://id.singpass.gov.sg/userinfo
JWKS: https://id.singpass.gov.sg/.well-known/keys

Additional Resources

Official Documentation

Support

Singpass Partner Support: partnersupport.singpass.gov.sg
Developer Portal: Check announcements for maintenance windows
Technical Issues: Contact Singpass support with error codes

Key Specifications

PKCE: RFC 7636
JWT: RFC 7519
JWE: RFC 7516
JWS: RFC 7515
DPoP: RFC 9449
Client Authentication: RFC 7523

License

This project is for demonstration purposes. Ensure compliance with Singpass terms of service and Singapore's PDPA when using MyInfo data.

Contributing

When contributing, ensure:

No private keys in commits
TypeScript types properly defined
Error handling comprehensive
Security best practices followed
Documentation updated

Last Updated: October 2025
MyInfo Version: v5
Next.js Version: 16.0.1

Table of Contents

Overview

Features

Prerequisites

Installation

1. Clone the Repository

2. Install Dependencies

Configuration

Singpass Developer Portal Setup

Step 1: Create a New App

Step 2: Configure App Settings

Step 3: Note Your Credentials

Key Generation

Generate Keys with OpenSSL

Important Notes:

Environment Variables

Create .env file

For Production Deployment

Important Environment Variable Notes:

Deployment

Docker Deployment

1. Build the Docker Image

2. Start the Application

3. Configure Reverse Proxy (e.g., Traefik, Nginx)

4. Verify JWKS Endpoint

Vercel/Railway Deployment

1. Set Environment Variables

2. Deploy

3. Configure Custom Domain

Testing

Testing in Staging Environment

1. Navigate to Your App

2. Click "Login with Singpass"

3. Use Test Credentials

4. Grant Consent

5. View Retrieved Data

Troubleshooting Test Issues

Architecture

OAuth 2.1 Flow Overview

Detailed Flow Steps

Step 1: Authorization Request

Step 2: User Authentication & Consent

Step 3: Authorization Callback

Step 4: Token Exchange

Step 5: Person Data Retrieval

Step 6: Data Decryption & Verification

Step 7: Display Data

API Routes

/api/auth/myinfo (GET)

/redirect (GET)

/.well-known/jwks.json (GET)

Security Features

PKCE (Proof Key for Code Exchange)

DPoP (Demonstration of Proof-of-Possession)

JWT Client Authentication

JWE/JWS Encryption

Session Management

Troubleshooting

Common Issues

1. "Request parameters invalid" (PX-E1000)

2. "Invalid JWKS object" (PX-E0101)

3. Token Exchange 401 Error

4. Userinfo 401 Error

5. Name Shows "Unknown"

6. Environment Variables Not Loading

Debug Mode

Production Checklist

Before Going Live

1. Security Audit

2. Singpass Portal Configuration

3. Infrastructure

4. Testing

5. Monitoring

6. Compliance

7. Production Endpoints

Additional Resources

Official Documentation

Support

Key Specifications

License

Create `.env` file

`/api/auth/myinfo` (GET)

`/redirect` (GET)

`/.well-known/jwks.json` (GET)
